NLS-HR-200 Scanner 2 Dimensi
Special Price : Call…..???
Inilah barcode scanner 2 dimensi yang memiliki kemampuan ganda selain membaca barcode umum 1 dimensi NLS-HR200 bisa membaca semua jenis barcode 2 Dimensi seperti PDF417, QR Code, Aztec Code, Maxi Code Dll. Tidak seperti barcode scanner 2 dimensi lainnya yang biasanya memiliki harga yang sangat mahal, NLS-HR200 di bandrol dengan harga yang relatif terjangkau bagi pasar domestik Indonesia yaitu sekitar USD 290.-
Untuk mengetahui lebih jelas tentang barcode scanner NLS-HR200 mari kita lihat spesifikasi detil dibawah ini:
Contoh barcode 2 dimensi
Specification Barcode Scanner 2D NLS HR 200 Newland
|
Performance
|
||
|
Image Sensor
|
CMOS
|
|
|
Resolution
|
752 * 480
|
|
|
Interface
|
RS232 / HID-KBW / UDP / USB COM Port Emulation / HID-POS / PS2-KBW / BlueTooth
|
|
|
Symbologies
|
2D
|
PDF417, QR Code(Model 1/2), Data Matrix(ECC200, ECC000, 050, 080,100,140), Aztec, Maxicode, LP Code, etc.
|
|
1D
|
Code128, EAN-13, EAN-8, Code39, UPC-A, UPC-E, Codabar, China post 25, Interleaved 2 of 5, ISBN/ISSN, Code 93, UCC/EAN-128, GS1 Databar,etc.
|
|
|
Precision
|
≥ 3mil
|
|
|
Light Source
|
LED(630 nm ± 10 nm)
|
|
|
Light Intensity
|
300 LUX (130 mm )
|
|
|
Depth of Scan Field
|
45 mm ~ 450 mm
|
|
|
Print Contrast Signal
|
≥ 25%
|
|
|
Roll
|
360°
|
|
|
Pitch
|
45°
|
|
|
Yaw
|
45°
|
|
|
Illumination
|
0 ~ 100,000 LUX
|
|
|
Electricals
|
||
|
Power Consumption
|
1.65 W
|
|
|
Voltage
|
DC 5 V
|
|
|
Current
|
Max
|
330 mA
|
|
Working
|
290 mA
|
|
|
Idle
|
200 mA
|
|
|
Weight
|
250 g
|
|
|
Enviroment
|
||
|
Operate Temperature
|
-5℃ - +45℃
|
|
|
Storage Temperature
|
-40℃ – +60℃
|
|
|
Humidity
|
5% – 95%(non-condensing)
|
|
|
Programming Software
|
Quick Set, Programming Guide, uTools Lite
|
|
|
Certification
|
FCC Part15 Class B, CE EMC Class B
|
|
| Field of View |
|
|
| Decode Distances |
| Barcode | Density (mil) | Near (mm) | Far (mm) |
| Code 39 | 5 | 55 | 115 |
| Code 39 | 10 | 30 | 21.5 |
| PDF417 | 5 | 50 | 105 |
| PDF417 | 10 | 30 | 215 |
| QR Code | 10 | 25 | 135 |
| QR Code | 15 | 25 | 210 |
| Data Matrix | 10 | 25 | 150 |
| Data Matrix | 15 | 20 | 220 |
